XFP-455 frozen Meat slicer
introduction:
- Slicing part: driven by a single motor and controlled by a frequency converter, the cutting knife speed can be adjusted according to different materials;
- Feeding part: driven by a servo motor, can be adjusted arbitrarily within the range of 0.5 ~ 100mm
Control & Operation:
- This machine adopts a frequency converter to control the drive motor;
- PLC touch screen
Performance:
- International advanced cutting motion mode – six-guide column linear positioning motion cutting structure.
- Flexible disassembly – the feeding plate can be disassembled and cleaned directly by hand .
- Cleaning method – direct cleaning with a water gun
- Safety Device – Inductive Automatic Circuit Break.
- Applications – Frozen meat slices, bars, blocks, rolls.
Technical Features:
| Material | SUS 304SS |
| Slicing Speed | 35-85slices/min |
| Dimension | 2800*1200*1600mm |
| Feeding Bin Size | 455(W)*180(H)*700(L)mm |
| Slicing Thickness | 0.5-100mm Adjustable |
| Slicing Temperature | -10℃ - 0℃ |
| Recommend Sllice Temp. | -6℃ - -5℃ |
| Power | 9.12KW |
| Voltage | 380V,50HZ (Customize) |
| Weight | 1100kg |
